- Specifications
- AD Conversion
- 24 bits + AF method
AF method (Adaptive Focus method) This is a proprietary method from Roland & BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA converters. - DA Conversion
- 32 bits
- Sampling Frequency
- 48 kHz
- Nominal Input Level
- -20 dBu
- Maximum Input Level
- +7 dBu
- Input Impedance
- 1 MΩ
- Nominal Output Level
- -20 dBu
- Maximum Output Level
- +7 dBu
- Output Impedance
- 1 kΩ
- Recommended Load Impedance
- 10 kΩ or greater
- Bypass
- Buffered bypass
- Controls
- BALANCE knob
SHIFT knob
PEDAL MODE switch
SHIFT DIRECTION switch
Pedal switch - Indicator
- CHECK indicator (Used for check battery)
- Connectors
- INPUT jack: 1/4-inch phone type
OUTPUT jack: 1/4-inch phone type
CTL/EXP jack: 1/4-inch TRS phone type
DC IN jack - Power Supply
- AC adaptor
Alkaline battery (6LR61 or 6LF22, commercially available) x 1 - Current Draw
- 120 mA
- Expected battery life under continuous use
- Alkaline battery (6LR61): Approximately 3 hours
